JL Audio HX280/4-PKG

JL Audio HX280/4 Compact 4-Channel Car Amplifier 50 watts RMS x 4

• Monoblock Class D Full Range Amplifier

• RMS Power Rating @ 14.4 V:

• 4 ohms: 50 watts x 4 chan.

• 2 ohms: 70 watts x 4 chan.

• Bridged 4 ohms: 140 watts x 2 chan.

• RMS Power Rating @ 12.5 V:

• 4 ohms: 36 watts x 4 chan.

• 2 ohms: 52 watts x 4 chan.

• Bridged 4 ohms: 100 watts x 2 chan.

• Channel Input Mode Switch: 2 / 3 / 4

• Switchable filter modes: Low-Pass / High-Pass

• Variable filter: 35 - 300 Hz, 12 dB/octave

• Frequency Response: 20 - 20,000 Hz

• Total Harmonic Distortion (THD): <1.0%

• Signal to Noise Ration: 89.5 dB

• Damping Factor: >60

• Fuse Rating: 35A x 1

• Dimensions: 8.66"W x 3.09"D x 1.77"H

• 8 gauge power and ground wiring is recommended for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.

• NexD™ ultra-high-speed switching design

• Black powder-coated finish

• Gasketed cover for the controls

• Stainless steel hardware for durability

• LED power (green) and protect (red) indicators

• Accepts RCA (low-level) & Speaker-level (high-level) signal

• Switchable Input sensitivity: 250 mV-4 V (Low) to 750 mV-15 V (High)

PowerBass AWK-80 8 Gauge Amplifier Installation Kit

• 17' Double Shielded RCA Cable

• 17' Blue 4-gauge 50/50 Power Cable

• 7' Silver 4-gauge 50/50 Ground Cable

• 20' Blue/Silver 16-gauge Speaker Wire

• 17' Blue Turn-On Wire

• 1 AGU Fuse Holder with 80A Fuse

• 6' Split Loom Protective Wire Tubing

• 2 8-gauge Gold Ring Terminals

• 2 8-gauge Gold Spade Terminals 4 Speaker Spade Terminals

• 1 Turn-On Spade Terminals

• 10 Black Cable Ties 3 x 150mm

• 2 Rubber Grommets
