$140.00
15" 800W 4-Ohm Punch Series Stage 2 Dual Voice Coil Subwoofer (P2D415)
General Features
Power Handling
- 400W RMS
- 800W Max
General Features
- Custom 10-AWG nickel plated push terminals
- Diamond cut cast aluminum trim ring with optional grille
- Dual linear spider with embedded 16 AWG tinsel leads
- Extended pole piece and bumped vented backplate
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Kevlar fiber reinforced paper cone
- Protective PVC textured magnet cover
- StampCast basket with integrated spider venting
- CEA-2031 compliant
- Flex fit basket
- Stitched tinsel leads
- Anodized aluminum voice coil former
General Specifications
- Voice Coil Diameter: 2.25"
- Speaker Connector: Dual 10 AWG compression
- Fs (Hz): 20
- Qts: 0.62
- Vas (Liters): 219.6
- SPL (dB @ 1w/1m): 86
- Xmax (mm): 10
- Woofer Displacement: 0.066 cu.ft.
- Cutout Diameter: 13.94"
- Mounting Depth: 7.34"
