$155.00
15" 300W SVC 4-Ohm W0 Series Component Car Subwoofer Driver
General FeaturesRecommended Enclosures:
- Sealed: 1.875 cu ft
- Ported: 2.75 cu ft
- DMA Optimized Motor System
- Elevated Frame-Cooling
- Free Air Resonance (Fs): 24.43 Hz
- Electrical "Q" (Qes): 0.508
- Mechanical "Q" (Qms): 9.474
- Total Speaker "Q" (Qts): 0.482
- Equivalent Compliance (Vas): 5.106 cu. ft. / 144.60 liters
- One-Way, Linear Excursion (Xmax)*: 0.50 in. / 12.7 mm
- Reference Efficiency (no): 0.180%
- Efficiency (1W/1m)**: 88.20 dB SPL
- Effective Piston Area (Sd): 122.317 in. sq. / 0.0789 m sq.
- DC Resistance (Re): 3.555 ohm
- Nominal Impedance (Znom): 4 ohm
- Thermal Power Handling (Pt): 500W
- Driver Displacement: 0.109 cu. ft. / 3.09 liters
- Net Weight: 15.8 lbs. / 7.2 kg
